Configure OIDC (OpenID Connect) Okta With Elastic Stack Authentication

1. Introduction

Wazuh is an open-source security solution designed to help organizations detect and respond to security threats. It provides real-time threat detection, analysis, and response capabilities, allowing organizations to enhance their overall security posture. Wazuh can monitor network and system activity, detect anomalies and attacks, and generate alerts when suspicious events occur.

This document provides a step-by-step guide to configure Okta as an OpenID Connect (OIDC) Identity Provider for the Elastic Stack. By integrating Okta with Elastic using OIDC, users can authenticate using centralized Single Sign-On (SSO) while Elastic validates identity through Okta-issued access tokens.

This integration allows:

• Centralized authentication management
• Enforced corporate security policies
• Reduced password management overhead
• Scalable enterprise access control

2. What is Okta?

Okta is a cloud-based Identity and Access Management (IAM) platform that provides:

• Single Sign-On (SSO)
• Multi-Factor Authentication (MFA)
• User and group management
• Secure token-based authentication
• Identity federation across applications

Okta acts as the Identity Provider (IdP), validating users and issuing authentication tokens to applications such as Elastic.

3. What is OIDC (OpenID Connect)?

OpenID Connect (OIDC) is an authentication protocol built on OAuth 2.0 that enables secure user identification using JSON Web Tokens (JWT).

It is commonly used for:

• API-based authentication
• Token-based authorization
• Enterprise-grade Single Sign-On (SSO)
• Secure federated identity management

Key Concepts:

• Access Token – Used to authenticate API access
• ID Token – Contains user identity (email, username, name)
• Refresh Token – Renews expired tokens
• JWT (JSON Web Token) – Encrypted + signed identity payload

OIDC is recommended when you plan to integrate applications with Okta programmatically or using widgets and APIs.

4. Architecture Overview

User → Application → Okta → Token Validation → Application Access Granted

• Elastic redirects authentication to Okta
• User logs in using corporate credentials
• Okta issues tokens
• Elastic validates the token and grants access based on roles

5. Step 1 – Configure Application in Okta

5.1. Create OIDC Application

1. Login to Okta Admin Console
2. Navigate to Applications → Create App Integration
3. Select OIDC – OpenID Connect
4. Choose Web Application
5. Click Next

5.2. Application Settings

Configure:

• App name: Elastic OIDC
• Grant type: Authorization Code

Sign-in redirect URIs:

https://<kibana-host>/api/security/oidc/callback

Logout redirect URIs:

https://<kibana-host>/logout

Assign users or groups to okta application

NOTE : Don’t forget to replace all place holders with their actual values

5.3 Save Credentials

After creating the app, note:

• Client ID
• Client Secret
• Okta Domain (e.g. https://dev-123456.okta.com)

6. Step 2 – Role Mapping in Elastic

Map Okta usernames to Elastic roles in username you can add multiple of them.

POST /_security/role_mapping/oidc_kibana
{
  "roles": ["superuser"],
  "enabled": true,
  "rules": {
  "all": [
     { "field": { "realm.name": "oidc1" } },
     {
       "any": [
         { "field": { "username": "<ENTER_YOUR_USERNAME>" } },
         { "field": { "username": "<ENTER_YOUR_USERNAME>" } },
         { "field": { "username": "<ENTER_YOUR_USERNAME>" } }
        ]
       }
     ]
   }
 }

NOTE : Don’t forget to replace all place holders with their actual values

7. Step 3 – Configure Elasticsearch

Edit your elasticsearch.yml

xpack.security.authc.realms.oidc.oidc1:
order: 2
rp.client_id: "<client_id_from_okta>"
rp.response_type: "code"

rp.requested_scopes: ["openid", "email"]
rp.redirect_uri: "http://<kibana-host>/api/security/oidc/callback"
rp.post_logout_redirect_uri: "http://<kibana-host>/logout"
op.issuer: "<your_okta_domain>"
op.authorization_endpoint: "<your_okta_domain>/oauth2/v1/authorize"
op.token_endpoint: "<your_okta_domain>/oauth2/v1/token"
op.userinfo_endpoint: "<your_okta_domain>/oauth2/v1/userinfo"
op.endsession_endpoint: "<your_okta_domain>/oauth2/v1/logout"
op.jwkset_path: "<your_okta_domain>/oauth2/v1/keys"
claims.principal: email

Then restart your elasticsearch

NOTE : Don’t forget to replace all place holders with their actual values

8. Step 4 – Configure Kibana

Edit kibana.yml

xpack.security.authc.providers:
oidc.oidc1:
order: 0
realm: oidc1
description: "Login with Okta"
basic.basic1:
order: 1

9. Conclusion

OIDC integration with Okta enables enterprise-grade centralized authentication, reduces credential sprawl, and improves security posture while offering seamless user access to Elastic environments.
